Product Details

Product Description

With options to meet the needs of the most demanding landscape maintenance professionals, our top-rated Exmark Lazer Z X-Series zero-turn mowers represent the state-of-the-art in commercial mowers. Cutting deck options include our massive 96-inch UltraCut Flex Wing cutting deck and select models equipped with our exclusive cut quality enhancing Adapt Technology. Choose from rugged commercial-grade engines, including high-efficiency Electronic Fuel Injection (EFI) options equipped with our exclusive EGov and RED Technology, which can boost fuel efficiency by up to 41%. Lazer Z X-Series zero-turn mower models are available with UltraCut Series 6 decks in 52-, 60-, and 72-inch cutting widths, with or without Adapt Technology, or the 96-inch UltraCut Flex-Wing rear discharge cutting deck.

Regardless of the combination you choose for your Exmark Lazer Z zero-turn mower, you’ll ride in unmatched comfort thanks to our full-suspension seating system and smooth, easy-to-use controls that offer precision maneuverability. And from a long-term value standpoint, nothing beats the Exmark Lazer Z X-Series mower. It’s the perfect combination of power, productivity, and durability. That’s why it’s our top-of-the-line gasoline-powered mower and should be at the top of your list.

Dimensions

Mower Deck Widths: 52″, 60″, 72″, and 96″

Components & Decks

  • Blade Spindles: No maintenance, sealed and non-greasable spindles; 7.75″-diameter cutter housing with 30mm (1.18″) diameter spindle shaft, double row bearings, top and bottom, and splined blade driver.
  • Drive Tires: 24 x 12.0-12, 4-ply Turf Master®
  • Front Caster Tires: 13 x 6.5-6 smooth tread, semi-pneumatic tires.
  • Caster Forks: .50″ thick caster yoke arms.
  • Tractor Frame: Unibody, welded, heavy-duty 1.5″ x 3″ tubular steel.
  • Steering Control: Hydraulically dampened twin levers, adjust fore and aft. Adjustable dampeners (3 positions) to customize drive responsiveness. Also adjustable to 2 height positions.
  • Parking Brake: Lever-actuated disc brake.
  • Seat: Deluxe, two tone, bolstered seat with Elastomeric Vibration Control material. Mounted on innovative Seat Isolation System that provides operator isolation in all three planes of motion as well as fore-aft slide and seat flip-up.
  • Engine Brand: Kawasaki
  • Engine Series: V-Twin
  • Engine Speed: 3,750 RPM
  • Air Filter: Heavy-duty canister air filtration system
  • Fuel Type: Gas Carbureted
  • Fuel Capacity:12-gallon (45.4-L), single fuel tank with single fill location.
  • Fuel Indicator: Yes – electronic Sender
  • Drive: Hydro-Drive
  • Drive Description: Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, shock valve, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 16 cc pumps and 17.1 cubic inch motors.
  • Speed: Infinitely variable speed selection from 0–11.5 mph (18.5 kmph) forward, 0–7.0 mph (11.3 kmph) reverse
  • Width / Cutting Deck: 60″
  • Deck Style: Floating Deck
  • Deck Style Description: Full-floating UltraCut Series 6 with heavy-duty spindle. Side discharge standard with the option to bag or mulch.

Photo Gallery

KEY FEATURES

  • Hydro Drive, Simplified:  Our hydro drive system has no hoses to leak and just one easy-to-change belt. Only simple, annual maintenance is required. It also lowers the center of gravity for improved handling.
  • Unibody Frame:  Our one-piece body frame is a classic case of “less is more.” Because, fewer parts equal more strength. And, more durability. So, in the interest of accuracy, the Lazer Z’s unibody frame is actually a case of “less is way more.”
  • Less Time At The Pump: Gas-powered E-Series models have a single 8-gallon tank with one fill location.
  • On-Board Diagnostics: Check vital functions at a glance on the digital screen. An electronic fuel gauge with low fuel warning on all Lazer Z units, battery voltage warning, hour meter and OPC safety switch monitoring make troubleshooting easy.
  • Fewer Grease Points:  With just four grease points that only need annual greasing, the Lazer Z delivers maximum performance with minimum maintenance. Greaseless spindles and only four grease points on the entire machine.
  • Ultracut Series 4 Deck:  This full-floating deck uses maintenance free spindle with a splined blade driver to stop bolt tightening on impacts. And, our patented bearing design on idler arm pivots only needs annual service.
  • Tool-less Belt Removal:  Deck and hydro belt can be installed without using any tools.
